SAN Migration and moving files with ASM

Here’s a quick post to help with LUN, SAN or File migration when using Oracle ASM.

Please note that this is just an example method, and it not a definitive guide.
You need to ensure your approach is appropriate for your environment.

Did you know that you can add and drop disks on a diskgroup in a single command.
This saves Oracle from doing 2 REBAL actions and speeds things up considerably using a lot fewer resources.

sqlplus / as sysasm;

> ALTER DISKGROUP data
2   ADD  DISK 'ORCL:disk101','ORCL:disk102'
3   DROP DISK 'disk042'     ,'disk043'
4   REBALANCE POWER n;

Diskgroup altered.

You can monitor the REBAL operation:

select * from v$asm_operation;

GROUP_NUMBER OPERA PASS      STAT POWER ACTUAL SOFAR EST_WORK EST_RATE EST_MINUTES ERROR_CODE CON_ID
------------ ----- --------- ---- ----- ------ ----- -------- -------- ----------- ---------- ------
           6 REBAL REBALANCE  RUN     1      1    68    20397     3030           8                 0
           6 REBAL COMPAT    WAIT     1      1     0        0        0           0                 0

If you are just migrating from one SAN to another, without needing to move files between diskgroups, this is a really easy way to achieve it.

From Oracle 12.1 onwards. if you are moving Datafiles from one Diskgroup to a new Diskgroup, that’s straightforward too:

export ORACLE_SID=ORCL
sqlplus  / as sysdba

alter database move datafile '+DATA_DG/ORCL/DATAFILE/system.101.902468275' to '+NEW_DG';

Moving logfiles involves a drop and re-create, but it still fully online.
Take care if using DataGuard that you do not try to drop logfiles before they are archived and applied to the standby:

alter database  add logfile member '+NEW_DG' to group 1;
alter database drop logfile member '+DATA_DG/ORCL/ONLINELOG/group_1.102.902049284';

Moving tempfiles can be tricky. The default gets used really quickly after startup.

You need to add a tempfile and then get all processes to not be using the old tempfile before you can drop it [select * from gv$sort_usage]. Worst-case, this may involve a SHUTDOWN, then a STARTUP RESTRICT to stop processes connecting. Alternatively, create a new default TEMP tablespace and convince processes to use that one.

alter tablespace temp add  tempfile '+NEW_DG';
alter tablespace temp drop tempfile '+DATA_DG/ORCL/TEMPFILE/temp.204.992482742';

Moving controlfiles requires a stop and start of the database. There’s no on-line options here. I tend to do the following:

srvctl stop database -d ORCL

sqlplus / as sysdba
startup nomount
show parameter control_files


rman target /
restore controlfile to '+NEW_DG' from '+DATA_DG/ORCL/CONTROLFILE/current.291.939274434';

sqlplus / as sysdba
alter system set control_files='+NEW_DG/ORCL/CONTROLFILE/current.992.346677889'
                              ,'+FRA_DG/ORCL/CONTROLFILE/current.???.?????????'
                               scope=spfile sid='*';
shutdown

srvctl start database -d ORCL

To move your spfile in ASM is a 2-stage process which will automatically update your database config in grid control:

sqlplus / as sysdba
create  pfile='/tmp/ORCL.ora' from spfile;
create spfile='+NEW_DG'       from pfile='/tmp/ORCL.ora';

Moving a password file in ASM is straightforward too:
NOTE: you are not allowed to move OMF files names and you must copy files via their alias.

as grid:
asmcmd
cp +DATA_DG/ORCL/orapworcl +NEW_DG/ORCL/orapworclexit
as oracle:
srvctl modify database -d ORCL -pwfile +NEW_DG/ORCL/orapworclsrvctl config database -d ORCL | grep Password

If you are using Block Change Tracking, you may need to move that file too:

alter database disable block change tracking;
alter database enable block change tracking using file '+NEW_DG';

Finally, if you’re dropping disk groups don’t forget to modify the disk group dependencies in Grid Infra so your DB isn’t dependent upon groups you have now removed:

srvctl config datbase -d ORCL | grep Group
srvctl modify database -d ORCL -diskgroup 'NEW_DG,FRA_DG,other_DG'

I hope you found this quick guide useful.

UKOUG 2-Stream London SIG

ukoug_logoWe now have the agenda online for the UKOUG 2-stream London SIG, due to take place on 23rd February. There will be an RDBMS Stream and a RAC, Cloud, Infrastructure and Availability Stream.

Mark Rittman will be giving us a keynote talk, with an emphasis on kettles or eating dinner in the dark or the Hadoop cluster in his garage or, well, probably something IoT-related

There are some really cool other speakers too, from Oracle, Leading Consultancies and the odd Independent too (like me).

The full Agenda and Registration Info can be seen here:
https://www.ukoug.org/events/ukoug-database-and-rac-cia-joint-sig-23022017/

It would be lovely to see you there, and maybe for a beer afterwards too.

OTN Appreciation Day : FlashBack Query

I love OTN, and I love Flashback query. It is a feature looking for an application use-case, but it really can dig you out of a major problem, recovering data you have recently deleted.

Here’s a silly example of the power:

select * from important_data

NAME                 PHONE_NUMBER
-------------------- ------------------------------
Partner A            555-1234
Partner B            555-5678

The choice is made:
update important_data set name = 'Spouse' where name = 'Partner B'

1 row updated.

And the redundant data removed:
delete from important_data where name = 'Partner A'

1 row deleted.

And all is good.
select * from important_data

NAME                 PHONE_NUMBER
-------------------- ------------------------------
Spouse               555-5678

Wait 7... years?
host sleep 7

And the data is missing something?

NAME                 PHONE_NUMBER
-------------------- ------------------------------
Spouse               555-5678

Perhaps we need to reconstruct the deleted data using Flashback
What did the table look like?

select * from important_data AS OF TIMESTAMP (SYSTIMESTAMP - interval '7' second)

NAME                 PHONE_NUMBER
-------------------- ------------------------------
Partner A            555-1234
Partner B            555-5678

And we can use Flashback to re-create the data.
insert into important_data (name,phone_number)
(select 'Hell-eau...', phone_number from important_data AS OF TIMESTAMP (SYSTIMESTAMP - interval '7' second) where name = 'Partner A')

1 row created.

And the data is correct again.

NAME                 PHONE_NUMBER
-------------------- ------------------------------
Hell-eau...          555-1234
Spouse               555-5678

rollback?

Stats Collection Time Anomaly

Johnathan Lewis (@JLOracle) recently published a short post about Stats Collection Time, talking about the table dba_optstat_operation (and dba_optstat_operation_tasks ), which reminded me about (what I regard as) an anomaly in the output in the NOTES columns in Oracle 12C.

I won’t repeat why it’s useful to check these tables as Johnathans note and @MDWidlakes’s comment here should give you all you need to know.

The DBA_OPTSTAT_OPERATION.NOTES column contains the parameters passed into the DBMS_STATS command, so you know what was done. It also reports the DEFAULT used by the DBMS_STATS job. Well, it does if you call DBMS_STATS explicitly, but the standard overnight auto job just says “default”. Why doesn’t is expand on that the way the explicit call does? If the default was changed between runs, you may end up with very different results but with no indication why. Am I missing something?

The following 2 rows of data show the output from each run. Note that the DEFAULT for METHOD_OPT in this database has been changed from “FOR ALL COLUMNS SIZE AUTO” to “FOR ALL COLUMNS SIZE REPEAT”** but was not explicitly passed-in for either run.

DBMS_STATS.GATHER_SCHEMA_STATS – decodes the DEFAULTs

OPERATION : gather_schema_stats
TARGET    : MYSCHEMA
START_TIME: 15-SEP-16 07.04.47
END_TIME  : 15-SEP-16 07.09.02
STATUS    : COMPLETED
JOB_NAME  :
NOTES     : <params>
            <param name="block_sample" val="FALSE"/>
            <param name="cascade" val="NULL"/>
            <param name="concurrent" val="FALSE"/>
            <param name="degree" val="NULL"/>
            <param name="estimate_percent" val="DBMS_STATS.AUTO_SAMPLE_SIZE"/>
            <param name="force" val="FALSE"/>
            <param name="gather_fixed" val="FALSE"/>
            <param name="gather_temp" val="FALSE"/>
            <param name="granularity" val="AUTO"/>
            <param name="method_opt" val="FOR ALL COLUMNS SIZE REPEAT"/>
            <param name="no_invalidate" val="NULL"/>
            <param name="options" val="GATHER"/>
            <param name="ownname" val="MYSCHEMA"/>
            <param name="reporting_mode" val="FALSE"/>
            <param name="statid" val=""/>
            <param name="statown" val=""/>
            <param name="stattab" val=""/>
            <param name="stattype" val="DATA"/>
            </params>

Autotask Overnight Gather – doesn’t decode the DEFAULTs

OPERATION : gather_database_stats (auto)
TARGET    : AUTO
START_TIME: 15-SEP-16 22.01.20
END_TIME  : 15-SEP-16 22.38.40
STATUS    : COMPLETED
JOB_NAME  : ORA$AT_OS_OPT_SY_1212
NOTES     : <params>
            <param name="block_sample" val="FALSE"/>
            <param name="cascade" val="NULL"/>
            <param name="concurrent" val="FALSE"/>
            <param name="degree" val="DEFAULT_DEGREE_VALUE"/>
            <param name="estimate_percent" val="DEFAULT_ESTIMATE_PERCENT"/>
            <param name="granularity" val="DEFAULT_GRANULARITY"/>
            <param name="method_opt" val="DEFAULT_METHOD_OPT"/>
            <param name="no_invalidate" val="DBMS_STATS.AUTO_INVALIDATE"/>
            <param name="reporting_mode" val="FALSE"/>
            <param name="stattype" val="DATA"/>
            </params>







**as it should be in EVERY ORACLE DATABASE EVER from the start, to allow you to control the histograms that you need and need to maintain on your schema. The Oracle default approach of “everything is skewed, thousands of histograms everywhere please” is particularly painful for OLTP databases using Bind Variable. I’m sure some of Oracles Adaptive Optimization is to work around the bad things that happen under this particular scenario.



DOAG Conference + Exhibition

Another quick post to let you know I will be presenting at the German Oracle User Group Conference [DOAG], which runs from 14th-18th of November 2016

This is a huge conference and exhibition over 4 days with many DOAG_2016tracks and a vast array of great speakers.

I hope to see you in Nuremberg! It will be good. Oh, yes. Es wird gut sein



DOAG Konferenz + Ausstellung 2016

POUG 2-day event

Just a quick post to let you know I will be speaking, with a lot of other Oracle ACE and other excellent speakers at the Pint with/Polish Oracle User Group (Chapter IV), taking place on 7th/8th October in Warsaw. Click on Buy Ticket link to see some of the other speakers, or look at the images below.

Hope to see you there! Should be fabulous.



poug_speakers_1poug_speakers_2

Accessing STATUS columns efficiently

A frequently reoccuring design problem with relational databases is the issue locating unprocessed rows in a large table, so we know which rows of data are still yet to be processed.

The problem with a STATUS column is that it generally has low cardinality; there are probably only a handful of distinct values [(C)omplete, (E)rror, (U)nprocessed or something like that]. Most records will be (C)omplete. This makes STATUS a poor candidate for standard B-Tree indexation. In a high throughput OLTP database, using bitmap indexes is probably not an option due to concurrency.

[Aside: When coding flag columns in Oracle, ALWAYS use a VARCHAR2(1 CHAR) {or CHAR(1 CHAR) if you prefer, but a CHAR is a VARCHAR2 under the covers and occupies the same number of bytes}. This is in preferance to a NUMBER(1). which occupies more bytes for a “1” than a “0”, so when you update it, you run the risk of row migration, chained rows and a performance hit. Frequently, ORM’s like Hibernate code for NUMBER by default. Override this!]

So what are my options? There’s a short list of possible table accesses for a low cardinality column.

1. Table scan. In an OLTP database where you only want a tiny fraction of the rows in the table, this would be a bad chouce.
2. Index the accessed columns and accept the inevitable INDEX_SCAN or FAST_FULL_INDEX_SCAN. This is not great and you probably need a Histogram on the column to convince the optimizer to use the index for your low frequency values. Otherwise you may be back to the table scan.
3. Make the “Complete” status “NULL”.
4. Uses a function-based index which makes the Complete status seems to be NULL for a specific query.

So what’s with options 3 and 4, why are they good, and how do we use them?

Unlike some RBDMS’s, Oracle does not store NULL values in it’s simple (non-composite) b-tree indexes. Therefore, if you choose Option (3) and make your “Complete” status be represented by a NULL, you will maintain an index on STATUS in which the only values that are stored are values you are interested in. This makes the index very sexy to the optimizer as it will generally be very tiny. However, we face one small problem. Convincing Developers that having a NULL as a valid status can be difficult. A NULL is a non-representative value. It is not supposed to represent anything. It means “I don’t know”. It doesn’t behave the same an normal values. This tends to freak out Developers and designers sometimes.

That’s where Option 4 comes in. If we wrap the index definition in a CASE statement, to produce a function-based index, we have have a highly specific tailored index on our table. If the SQL predicate matches the query exactly, we get a serious performance payoff.

But don’t take my word for it. Here’s a worked example from my laptop:


Here’s the table, it’s data distribution (16m rows, and a handful we care about)

NEIL @ ORCL01 > desc test_table
 Name                          Null?    Type
 ----------------------------- -------- --------------------
 ID                            NOT NULL NUMBER
 STATUS                        NOT NULL VARCHAR2(1 CHAR)
 DESCRIPTION                   NOT NULL VARCHAR2(100 CHAR)

NEIL @ ORCL01 > select status,count(*) from test_table group by status

S   COUNT(*)
- ----------
E         16
C   16777216
Y         32


Here are the indexes on the table, and their sizes. As you can see, the function-based index is absolutely tiny, making it as attractive to storage admins as it is to the optimizer.

- alter table test_table add constraint test_table_pk primary key (id);
- create index test_table_CASE on test_table (case status when 'Y' then status else null end);
- create index test_table_COVER_COMP on test_table (status, id) compress 1;
- create index test_table_STATUS on test_table (status) compress 1;



NEIL @ ORCL01 > select segment_name,segment_type,sum(bytes/1024) kb from user_extents
where segment_name like 'TEST_TABLE%'
group by segment_type,segment_name order by 2 desc,1;

SEGMENT_NAME               SEGMENT_TYPE               KB
-------------------------- ------------------ ----------
TEST_TABLE                 TABLE                  555008
TEST_TABLE_CASE            INDEX                      64
TEST_TABLE_COVER_COMP      INDEX                  658432
TEST_TABLE_PK              INDEX                  319488
TEST_TABLE_STATUS          INDEX                  413696

Some Index stats:
INDEX_NAME                DISTINCT_KEYS AVG_LEAF_BLOCKS_PER_KEY AVG_DATA_BLOCKS_PER_KEY CLUSTERING_FACTOR STATUS     NUM_ROWS SAMPLE_SIZE LAST_ANAL
------------------------- ------------- ----------------------- ----------------------- ----------------- -------- ---------- ----------- ---------
TEST_TABLE_CASE                       1                       1                       6                 6 VALID            32          32 21-FEB-16
TEST_TABLE_COVER_COMP          16748149                       1                       1            125447 VALID      16748149      234974 21-FEB-16
TEST_TABLE_PK                  17003239                       1                       1             91391 VALID      17003239      492287 21-FEB-16
TEST_TABLE_STATUS                     3                   13828                   32011             96034 VALID      16257590      363295 21-FEB-16


Where we have a choice of useful indexes, we get a FAST FULL SCAN with a hefty cost. A histogram could have given us an index RANGE SCAN, which can be very good.
With no Histogram:

select id from test_table where status = 'Y';

Plan hash value: 1140618830

----------------------------------------------------------------------------------------------
| Id  | Operation            | Name                  | Rows  | Bytes | Cost (%CPU)| Time     |
----------------------------------------------------------------------------------------------
|   0 | SELECT STATEMENT     |                       |       |       | 18753 (100)|          |
|*  1 |  INDEX FAST FULL SCAN| TEST_TABLE_COVER_COMP |  5592K|    42M| 18753   (1)| 00:00:01 |
----------------------------------------------------------------------------------------------


With a histogram in place on STATUS, you get a much better plan as the covering index avoids the need for the table look-up. You also get the risk that the optimizer may have bind variable peeking issues and other complications should we have lots of table joins.

select id from test_table where status = 'Y'

Plan hash value: 2912582684

------------------------------------------------------------------------------------------
| Id  | Operation        | Name                  | Rows  | Bytes | Cost (%CPU)| Time     |
------------------------------------------------------------------------------------------
|   0 | SELECT STATEMENT |                       |       |       |     3 (100)|          |
|*  1 |  INDEX RANGE SCAN| TEST_TABLE_COVER_COMP |    32 |   256 |     3   (0)| 00:00:01 |
------------------------------------------------------------------------------------------

NOTE: Ditching the covering index and just using the index on STATUS is pretty efficient too when combined with a histogram:

select id from test_table where status = 'Y'

Plan hash value: 2416598805

---------------------------------------------------------------------------------------------------------
| Id  | Operation                           | Name              | Rows  | Bytes | Cost (%CPU)| Time     |
---------------------------------------------------------------------------------------------------------
|   0 | SELECT STATEMENT                    |                   |       |       |     4 (100)|          |
|   1 |  TABLE ACCESS BY INDEX ROWID BATCHED| TEST_TABLE        |    32 |   256 |     4   (0)| 00:00:01 |
|*  2 |   INDEX RANGE SCAN                  | TEST_TABLE_STATUS |    32 |       |     3   (0)| 00:00:01 |
---------------------------------------------------------------------------------------------------------



And now with the function-based index; having the case statement removing all statuses we are not interested-in for a tiny tidy index.

NOTE: The Predicate in the query must EXACTLY match the function-based index for it to be used.

select id from test_table where case status when 'Y' then status else null end = 'Y'

Plan hash value: 2073004851

-------------------------------------------------------------------------------------------------------
| Id  | Operation                           | Name            | Rows  | Bytes | Cost (%CPU)| Time     |
-------------------------------------------------------------------------------------------------------
|   0 | SELECT STATEMENT                    |                 |       |       |     7 (100)|          |
|   1 |  TABLE ACCESS BY INDEX ROWID BATCHED| TEST_TABLE      |    32 |   256 |     7   (0)| 00:00:01 |
|*  2 |   INDEX RANGE SCAN                  | TEST_TABLE_CASE |    32 |       |     1   (0)| 00:00:01 |
-------------------------------------------------------------------------------------------------------

Conclusion: For a highly skewed STATUS column you need a histogram, which is something you should mostly avoid in OLTP systems using BIND variables. Having a highly focussed function-based index allows for a tiny self-maintaining index which is guaranteed to only be used for queries that you want it to be used for.


NOTE: The original idea behind using NULLS to minimise index size came from the performance expert, Jonathan Lewis. I have implemented both NULL-as-complete design and case-based indexes at several clients, in varying forms, and always to great success.

%d bloggers like this:
