Oracle Optimizer System Statistics

System Statistics Are a Little Complex

Oh System statistics! Should we gather them? Should we not?
What do they mean? What are they doing to the optimizer?


First you need to be armed with a piece of information. When Oracle optimizes your SQL, it produces a COST to compare each SQL execution plan. Exactly what is this COST? It’s not seconds. It’s not quite the amount of I/O required. It’s not an arbitrary figure either. Oracle Optimizer Cost is the cost of getting your data in terms of SINGLE BLOCK READS. Remember this for later.

Lets have a look at the system stats defaults :

SELECT sname,pname,pval1 FROM SYS.AUX_STATS$ ORDER BY 1,2;
SNAME                PNAME                               PVAL1
-------------------- ------------------------------ ----------
SYSSTATS_INFO        FLAGS                                   0
SYSSTATS_MAIN        CPUSPEEDNW                           2911 (this will vary)
SYSSTATS_MAIN        IOSEEKTIM                              10
SYSSTATS_MAIN        IOTFRSPEED                           4096

What we are looking for here is the the 3 metrics highlighted in colour. As we can see, the are not set. By default, we need to calculate those, or know where to find the defaults for those values to get to them. Once we have those 3 metrics, we can calculate the RATIO used by the optimizer to convert MULTIBLOCK READ into a cost metric of SINGLE BLOCK READS.

The CPU speed is used to calculate the COST of the query in terms of CPU required. This is small percentage of the query cost but it may help decide which plan is chosen. This is also converted from CPU cost into a cost metric of SINGLE BLOCK READS.

Lets get the values for MBRC, MREADTIM and SREADTIM.

MBRC is easy. If it is not explicitly set, it uses the init.ora parameter “db_file_multiblock_read_count” and uses that. However, by default (and also my recommendation) this should not be set, meaning Oracle will use the hidden parameter “_db_file_optimizer_read_count” to cost your queries. This defaults to 8. [note: this is not the value used in execution. Oracle attempts to do 1MB reads, and uses the value in “_db_file_exec_read_count” to control the multiblock reads at execution time. For an 8K block size, this is set to 128.

SREADTIM and MREADTIM are calculations based upon information we now have:
SREADTIM = IOSEEKTIM + db_block_size        / IOTFRSPEED = 10+(8192 /4096) = 12
MREADTIM = IOSEEKTIM + db_block_size * MBRC / IOTFRSPEED = 10+(8192*8/4096) = 26

Right! Now we have more information and can calculate a ratio. The multi block cost-per-block. This will allow us to take the number of blocks in (for example) a table scan [DBA_TAB_STATISTICS.BLOCKS statistic] and covert it to the cost metric os SINGLE BLOCK READS, meaning we can compare (for example) a FULL TABLE SCAN’s I/O directly with the I/O required for an Index Range Scan and Table Lookup.

multi-block cost-per-block = 1/MBRC * MREADTIM/SREADTIM = 1/8 * 26/12 = 0.270833

If we pull some data from a 10053 trace, where I have a table scan of a table containing 1,000,000 blocks, we should see the 1,000,000 blocks being converted to 270,833 “single block read blocks” for COST purposes.

  Single Table Cardinality Estimation for COST_CHECK[COST_CHECK]
  SPD: Return code in qosdDSDirSetup: NOCTX, estType = TABLE
    Card: Original: 1000000.000000  Rounded: 1000000  Computed: 1000000.000000  Non Adjusted:1000000.000000
  Scan IO  Cost (Disk) =   270835.000000
  Scan CPU Cost (Disk) =   7411440000.000001
  Total Scan IO  Cost  =   270835.000000 (scan (Disk))
                       =   270835.000000
  Total Scan CPU  Cost =   7411440000.000001 (scan (Disk))
                       =   7411440000.000001
  Access Path: TableScan
    Cost:  271041.492812  Resp: 271041.492812  Degree: 0
      Cost_io: 270835.000000  Cost_cpu: 7411440000
      Resp_io: 270835.000000  Resp_cpu: 7411440000
  Best:: AccessPath: TableScan
         Cost: 271041.492812  Degree: 1  Resp: 271041.492812  Card: 1000000.000000  Bytes: 0.000000

Well we were close! There’s a fudge factor in play here, but 270,835 is pretty much 270,833 🙂

We can also work out the CPU element of the COST.
Scan IO  Cost (Disk) =   270835.000000
Cost: 271041.492812
so CPU cost must be 271041.492812 – 270835.000000 = 206.492812

Scan CPU Cost (Disk)=7411440000.000001 so doing the maths to convert to units of “single block read time”…

CPUSPEEDNW = 2,991 (Mhz, but we convert 2,991,000 Khz)

= 7,411,440,000 / 2,991,000 / SREADTIM
=  ‭2,477.913741223671013039 / 12
‭= 206.49281176863925108659311267135‬ cost of CPU in units of SREADTIM

So now you can see how your system statistics can fundamentally change the optimizer by changing the ratio of multiblock-reads to single block reads.

You want to play yourself and see what happens? Of course you do…

Here’s an excel spreadsheet where you can plug in your numbers and see what happens to the ratio between single and multi block reads to see how system stats influence the optimizer. By plugging in different numbers, you will see how complex the interactions are – so what’s the ideal numbers? Use the DEFAULTS in almost all cases** [WARNING – don’t go changing your system stats based on this statement. You might experience a significant amount of plan changes, some of which may be very very bad!]:

Also, this is my version of a script by Franck Pachot, and also based on work by Chris Antognini, which you can run against your system:

select pname,pval1,calculated,formula from sys.aux_stats$ where sname='SYSSTATS_MAIN'
reference sga on (
select 'Database Buffers' name,sum(bytes) value from v$sgastat where name in ('shared_io_pool','buffer_cache')
) dimension by (name) measures(value)
reference parameter on (
select name,decode(type,3,to_number(value)) value from v$parameter where name='db_file_multiblock_read_count' and ismodified!='FALSE'
union all
select name,decode(type,3,to_number(value)) value from v$parameter where name='sessions'
union all
select name,decode(type,3,to_number(value)) value from v$parameter where name='db_block_size'
union all
SELECT a.ksppinm name, to_number(b.ksppstvl) value FROM x$ksppi a, x$ksppsv b WHERE a.indx=b.indx AND ksppinm like '_db_file_optimizer_read_count'
dimension by (name) measures(value)
partition by (sname) dimension by (pname) measures (pval1,pval2,cast(null as number) as calculated,cast(null as varchar2(120)) as formula) rules(
calculated['MREADTIM']=coalesce(pval1['MREADTIM'],pval1['IOSEEKTIM'] + (parameter.value['db_block_size'] * calculated['MBRC'] ) / pval1['IOTFRSPEED']),
calculated['SREADTIM']=coalesce(pval1['SREADTIM'],pval1['IOSEEKTIM'] + parameter.value['db_block_size'] / pval1['IOTFRSPEED']),
calculated['_multi block Cost per block']=round(1/calculated['MBRC']*calculated['MREADTIM']/calculated['SREADTIM'],4),
calculated['_single block Cost per block']=1,
formula['MBRC']=case when pval1['MBRC'] is not null then 'MBRC' when parameter.value['db_file_multiblock_read_count'] is not null then 'db_file_multiblock_read_count' when parameter.value['_db_file_optimizer_read_count'] is not null then '_db_file_optimizer_read_count (db_file_multiblock_read_count not set, which is good!)' else '= not sure so used 8' end,
formula['MREADTIM']=case when pval1['MREADTIM'] is null then '= IOSEEKTIM + db_block_size * MBRC / IOTFRSPEED' end||' = '||pval1['IOSEEKTIM']||'+('||parameter.value['db_block_size']||'*'||calculated['MBRC']||'/'||pval1['IOTFRSPEED']||')',
formula['SREADTIM']=case when pval1['SREADTIM'] is null then '= IOSEEKTIM + db_block_size / IOTFRSPEED' end||' = '||pval1['IOSEEKTIM']||'+('||parameter.value['db_block_size']||'/'||pval1['IOTFRSPEED']||')',
formula['_multi block Cost per block']='= 1/MBRC * MREADTIM/SREADTIM = 1/'||calculated['MBRC']||' * '||calculated['MREADTIM']||'/'||calculated['SREADTIM'],
calculated['_maximum mbrc']=sga.value['Database Buffers']/(parameter.value['db_block_size']*parameter.value['sessions']),
formula['_maximum mbrc']='= buffer cache blocks/sessions (small cache limiter) = ' || sga.value['Database Buffers']/parameter.value['db_block_size']||'/'||parameter.value['sessions'],
formula['_single block Cost per block']='relative to the multi blovk cost per block. Always 1!',
formula['CPUSPEED']='overrides CPUSPEEDNW when set',
formula['CPUSPEEDNW']='CPU speed Mhz - non workload',
formula['IOSEEKTIM']='IO seek time in ms',
formula['IOTFRSPEED']='IO transfer speed in KB/s',
formula['MAXTHR']='Maximum IO system throughput',
formula['SLAVETHR']='average parallel slave IO throughput'
) order by 1;

** there is a case for gathering ‘exadata’ system stats. Increasing the IOTRFSPEED to 200,000 and changing the MBRC to (probably) 128 or 64 will *really* change the ratios, forcing a lot of full table scans down onto the storage cells, instead of using mediocre indexes. This should be considered (and thoroughly tested) if you have a DW on a dedicated Exadata. From a little more on exadata stats, check this blog post

3 Responses to Oracle Optimizer System Statistics

  1. Pingback: Exadata System Statistics | Neil Chandler's DB Blog

  2. Laverde Williams says:

    As always, good on to read.
    In case a gathered system statitics and performance went wild. Can I just delete system stats and restart or just delete it and regather them noworkload without restart?


    • There are no restarts required with the statistics, although a hard parse will be needed to get new execution plans. You can just delete the stats and they should revert to the defaults.

      Always bear in mind, changing system stats can change the execution plan every SQL in the system and so is not without risk. Before changing them, It is a good idea to record every explicitly set value in sys,aux_stats$, so you have a rollback capability.
